he GWN7624 is an in-wall Wi-Fi access point designed for small-to-medium sized businesses, offices, residential and
commercial locations, hotels and more. It provides three Gigabit network ports to provide IP phones, IPTV, computers
and similar devices with Ethernet while also providing and uplink Gigabit network port with PoE/PoE+.
The GWN7624 offers 2.4G 2×2:2 MIMO, 5G 4×4:4 MU-MIMO technology and a sophisticated antenna design for maximum network
throughput and expanded Wi-Fi coverage range. This access point is designed to be mounted in-wall to provide a
clean and professional installation that blends into the surrounding environment. To ensure easy installation and
management, the GWN7624 uses a controller-less distributed network management design in which the controller is
embedded within the product’s web user interface. The GWN7624 is also supported by GDMS Networking and GWN
Manager, Grandstream’s free cloud and on-premise Wi-Fi management platform.
It is the ideal Wi-Fi AP for voice-over - Wi-Fi deployments and offers a seamless connection with Grandstream’s Wi-Fi capable IP phones. With support for
advanced QoS, low-latency real-time applications, mesh networks, captive portals and 200 concurrent clients per AP,
the GWN7624 is an ideal Wi-Fi access point for medium wireless network deployments with medium user density
Overview
Make
Grandstream
Model
GWN7624
Product Type
Indoor Wifi Access Points
Gigabit
2.03 Gbps wireless throughput and 4 Gigabit wireline ports 5GHz
MIMO
Dual-band 2×2:2 2.4GHz 4×4:4 5GHz
Concurrent Devices
Supports upto 200 concurrent Wi-Fi client devices
Range
Up to 100 meters coverage range
PoE
Self power adaptation upon auto detection of PoE/PoE+
Warranty
3 year Official Warranty
Features
(✓) 2.03 Gbps wireless throughput and 4 Gigabit wireline ports
(✓) Dual-band 2×2:2 2.4GHz 4×4:4 5GHz
(✓) Self power adaptation upon auto detection of PoE/PoE+
(✓) Supports up to 200 concurrent Wi-Fi client devices.
(✓) Up to 100-meter coverage range.
(✓) Advanced QoS to ensure real-time performance of low-latency applications.
(✓) Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device.
